WaveX Dock Modular Dock System

WaveX Modular Dock System

R&J’s exclusive side extruded aluminum docking incorporates all the high end features without the associated costs. Our WaveX dock was designed as a mid-weight, low profile deck ideally suited for canoes, kayaks, and mid-sized boats.

Our WaveX docks are available in frame only configuration or with 2’ removable decking panels in 1-1/4” PT Sienna, Western Red Cedar or PVC Decking.
Decking panels are available in 5/4 PT Sienna, Western Red Cedar, PVC Decking or optional aluminum decking. WaveX Modular docks are available in 10′ lengths, and 4′, 6′ and 8′ widths which allows for endless dock configurations.

Features included:

– R & J’s decking hold down trim
– Extruded heavy-duty leg holders receivers which accept 2- 3/8” OD pipe legs
– Aluminum connecting hinges

Designed as a mid-weight, low profile dock ideally suited for canoes, kayaks, and mid-sized boats.

Designed as a mid-weight, low profile dock ideally suited for canoes, kayaks, and mid-sized boats.

Ramp Section

– Aluminum hold down trim to hold decking panels firmly in place
– Stainless steel hardware
– 1 pair of aluminum hinges
– Frame only weight 90 – 134 lbs. depending on width



Stand Alone Dock Section

– Aluminum hold down trim to hold decking panels firmly in place
– Stainless steel hardware
– 2 pair of aluminum hinges (one on each end of frame)
– 4 heavy duty leg collars c/w 5’ dock leg and foot pad
– Frame only weight 112 – 146 lbs. depending on width



Add on Dock Section

– Aluminum hold down trim to hold decking panels firmly in place
– Stainless steel hardware
– 1 pair of aluminum hinges
– 2 heavy duty leg collars c/w 5’ dock leg and foot pad
– Frame only weight 96 – 140 lbs. depending on width



green spawn fish white & mod - transparent
Fish Friendly Dock Structure – Pipe docks have minimal contact with the lake bed because only the base of the legs come in contact with the lake bottom. They provide minimal shading of aquatic plants and the height  can be adjusted with water fluctuation. Pipe docks allow the water to flow freely beneath the framework while still providing a shaded, protected area for fish to gather.
